You will be amazed by the stunning image quality of HIK. It’s like comparing the difference between a VHS video tape and a Blu-Ray movie, allowing you to see details and colors like never before.

This camera must be connected to a DVR otherwise it can not work alone!

If an incident occurs you can transfer video files to back-up media via the easily accessible USB port or save to your network at night or during day time.

It also has Night vision meaning you can still view images even if its night outside. After the sun sets, the security camera automatically changes to night view. With a combination of over 40 infrared sensors,the security camera can capture criminal activity in the darkness with almost the same clarity as its daytime equivalent .

Monitor the perimeter of your business or home also when it is pitch black outside. After the sun sets, the security camera automatically changes to night view. With a combination of over 40 infrared sensors,the security camera can capture criminal activity in the darkness with almost the same clarity as its daytime equivalent .

Technical Features

Remote viewing is by your Smartphone or PC anywhere every where! -(This can be done using a router. Not included)

• H.264 /H.264+& Dual-stream video compression

• Support both HD-TVI /analog and AHD cameras with

adaptive access

• Full channel recording at fast resolution

• HDMI and VGA output fast resolution

• Long transmission distance over coax cable

• Support 4ch synchronous playback at 720P resolution

Video/Audio Input

Audio Input: - 1-ch

Video Compression: - H.264,H.264+

Analog and HD-TVI video input: - 4-ch BNC interface (1.0Vp-p, 75 Ω)

Supported camera types: - Support HDTVI input: 1080P/25Hz, 1080P/30Hz, 720P/25Hz, 720P/30Hz,

Support AHD input: 720P/25Hz, 720P/30Hz,

support CVBS input

Video Input Interface: - BNC (1.0 Vp-p, 75Ω)

Audio Compression: - G.711u

Audio Input Interface: - RCA (2.0 Vp-p, 1 kΩ)

Two-way Audio: - 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using audio input)

Video/Audio Output

HDMI/VGA Output: - 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz

Recording resolution: - When 1080p Lite mode not enabled: 720p/WD1/4CIF/VGA/CIF;

When 1080p Lite mode enabled: 1080p lite/720p/WD1/4CIF/VGA/CIF

Frame Rate: - Main stream:

When 1080p Lite mode not enabled:

For 720p stream access: 720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

When 1080p Lite mode enabled:

1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

Video Bit Rate: - 32 Kbps ~ 4 Mbps

Stream Type: - Video/Video&Audio

Audio Output: - 1-ch RCA(Linear, 1kΩ)

Audio Bit Rate: - 64kbps

Dual Stream: - Support

Playback Resolution: - 1080p lite/720p/WD1/4CIF/VGA/CIF

Synchronous Playback: - 10-ch

Network management

Remote connections: - 32

Network protocols: - TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Interface Type: - 1 SATA Interface

Capacity: - Up to 6 TB capacity for each disk

External Interface

Network Interface: - 1; 10M / 100M self-adaptive Ethernet interface

USB Interface: - 2 USB 2.0 Interfaces

Specifications

Key Features

1. 1 Cameras,Dome shape camera
2.  Full HD Resolution
3. Long distance transmission over UTP and coaxial cable
4. True Day/Night, Smart IR HDMI and VGA output
5. Smartphone and PC viewing- playback at excellent resolution(Optional)

Specifications

1. SKU: HI857EA2QVNG4NAFAMZ
2. Weight (kg): 0.5
